Technical mirrors
Metallic or dielectric front surface mirrors
Front surface mirrors are special technical mirrors in which the reflective coating is applied to the front of the glass.
Depending on the technical application, front surface mirrors are designed according to your requirements. High reflections over a long wavelength range can be achieved with coatings of high-purity aluminum, silver, or gold. Maximum reflections well over 99% can be achieved for certain wavelength ranges with dielectric coatings.
Front-surface mirrors are used in many industries and areas, such as optical measurement technology, laser applications, microscopy, telescopes, and other optical systems. What are your requirements for front-surface mirrored glass plates? Together, we will find the most economical solution for you.
Technical specifications
Front surface mirror
Application
In the entire industry for mirrors or for special functions in your systems
Substrate material
Thin glasses, Floatglass, Borofloat; other materials on request
Dimensions
Standard thickness 1 to 6 mm; other thicknesses on request
Cut as per client’s requirements: round, angular, elliptical ...
Adhesion
According to DIN ISO 9211-4; S 02
Abrasion resistance
According to DIN ISO 9211-4; S 03
Temperature resistance
Depending on the substrate material up to 250 °C
Metrology
Mirrors
Designs
Front or rear surface mirror with metallic or dielectric coatings
Substrate material
Optical plane glasses, technical flat glasses
Coating
AAl, Ag, Au and Cr with or without dielectric protection layer
High reflective coatings for laser applications with minimum surface defects
For details refer to Optical coatings
Dimensions
1 to 1.700 mm
Larger dimensions on request
Shapes
Round, angular, elliptical or as required
Wavelength range
300 nm to 1.600 nm
Abrasion resistance & adherence
DIN ISO 9211-4
Thermal endurance
Up to 550°C depending on the coating and substrate material, hard and abrasion resistant, gas and waterless, long-term stability, insensitive against environmental conditions
Metrology
Achieving reproducible quality
With high-precision measurement technology
You need reliable high quality in our various precision optics, spherical optics, and technical glass products. We achieve this quality for you thanks to our high-quality measurement technology and measuring equipment.
Upon customer request, we will provide you with a test report containing all the required test characteristics. All materials used are tested in accordance with current specifications and certified upon request. We guarantee you consistently high quality!
- Visual defect inspection
- Angle measurement
- Parallelism measurement
- Interferometer evaluation
- Roughness measurement
- Spectral reflection and transmission measurement
Every prototype starts with an idea.
From the idea to series production.
From the idea to prototype production to the manufacture of spherical optics, high-precision flat optics, technical glass, or optical assemblies, we will find an efficient product solution for you.
Concept
No matter how challenging the task, we work with you to develop solutions tailored to your individual needs.
Design
Designing means developing the blueprint for a technical product in such a way that it can be manufactured. We have the relevant expertise and the necessary technical equipment to do this.
Production
Your product is manufactured in our production facility according to your individual specifications. Our many years of experience and modern machine and plant technology are a great advantage for you here.
Testing
All manufactured components undergo the necessary testing processes. The measurement results are documented accordingly.
Delivery
We deliver your components in standard packaging as well as in special packaging tailored to your specific requirements.
